To change the color or light show on a Pentair light connected to this system, you must use a rapid ON/OFF toggle at the main wall switch (or via automation/controller) within 10-15 seconds.
Standard Light Sequences (On/Off Cycles)
1 Turn: SAm Mode (White, Magenta, Blue, Green)
2 Turns: Party Mode (Rapid color change)
3 Turns: Romance Mode (Slow color change)
4 Turns: Caribbean Mode (Blues and Greens)
5 Turns: American Mode (Red, White, and Blue)
6 Turns: California Sunset Mode (Orange, Red, Magenta)
7 Turns: Royal Mode (Deep color tones)
8-12 Turns: Fixed colors (Blue, Green, Red, White, Magenta)
Important Operating Notes
1 White Start: When first turned on, the light will show white for a second before switching to the last saved color.
2 Save/Hold Color: To lock in a color, turn the light OFF, wait 5 seconds, then turn it ON.
3 Syncing Lights: If multiple lights are out of sync, turn the switch OFF/ON 11 times (or sometimes 31 times) to reset them all to white, then select your desired mode.
4 Safety Warning: During the ON/OFF switching process, there may be moments of no illumination.
5 If you are using a Pentair Automation System (IntelliTouch, EasyTouch, IntelliCenter), these sequences are automated through the menu, which handles the power cycling for you.
